Door Frame Metal Detector

Door Frame Metal Detectors (DFMD) are an invaluable deterent tool in today’s hi-threat environment. The DFMD detects ferrous, non ferrous metal and their alloys. With multipal alarms and battery back-ups, in a choice models, there is one suitable for every scenario.

SPECIFICATIONS

TYPE: 1 TYPE: 2 TYPE: 3
General Door frame is made up of sun mica within built WALK-STOP indicators. The complete electronics is placed on the top of the wooden frame with plug in card systems and IR sensors to avoid outside movement alarms.
  • Auto Tuning /Calibration Setting.
  • Advanced Microprocessor controlled induction loop.
  • Quick and Easy to install.
  • Membrane switches and Backlit LCD.
  • Uniform detection from Top to Bottom.
  • It has general immunity to electro magnetically noisy environments.
  • The DFMD is completely weather proof, rugged and designed for trouble free long life.
  • Four tone:
    Simple alarm for small metal.
    Fine alarm for medium metal.
    Police alarm for heavy metal.
    Diff erent tone for ferrite detection.
  • Type: 2 is a 9 (Nine) zone metal detector. The complete electronics is placed on the top of the frame with plug in card systems and IR sensors to avoid outside movement alarms.
  • 9 zones over-lapping zones with Left Top, Center Top, Right Top, Left Middle, Right Middle, Left Bottom, Center Bottom and Right Bottom.
  • Auto Tuning/Calibration Setting.
  • Advanced Microprocessor.
  • Quick and Easy to install.
  • Membrane switches and Backlit LCD.
  • Uniform detection from Top to Bottom.
  • It has general immunity to electro magnetically noisy environments.
  • The DFMD is completely weather proof, rugged and designed for trouble free long life.
  • Password protected along with mechanical key.
  • RS 232 compactable (OPTIONAL).
  • Traffic thru LED indicator.
  • Door frame is made up of flexible cable housed in telescopic extendable PVC pipe frame with clutch’s for quick release and locking systems is contained in the canvas carrying bags. The pipes can be joined to form a door frame by releasing the clutch.
  • The control unit is housed in a brief case. Wooden ramp for protection of coils and two wooden legs for stability of the frame are provided.
  • The entire system can be assembled in less than 5 minutes to form an archway door frame metal detectors. It has plug in card systems and IR sensors to avoid outside movement alarms.
  • Auto Tuning/Calibration Setting.
  • Advanced Microprocessor controlled induction loop.
  • Quick and Easy to install.
  • Uniform detection from Top to Bottom.
  • It has general immunity to electro magnetically noisy environments.
  • The DFMD is completely weather proof, rugged and designed for trouble free long life.
  • Four tone:
    Simple alarm for small metal.
    Fine alarm for medium metal.
    Police alarm for heavy metal.
    Diff erent tone for ferrite detection.
TECHNICAL
Technology Micro processor Micro processor Micro processor
Tuning Auto setting Auto setting Auto setting
Zone Single 9 (Nine) Single
Visual Display LCD/LED LCD/LED LCD/LED
Audio Four Tone Multiple Four Tone
Counter 5 digit IN, Out & NET IN 5 digit IN 5 digit IN, Out & NET IN
Sensor IR IR IR
Sensitivity Level 0 to 9 1 TO 150 0 to 9
Low battery Low battery & WALK-STOP Low battery Low battery Controls
Controls 0 to 5 Volume, Tone, Sensitivity 0 to 5
UPS >80 hrs >10 hrs >40 hrs
Power 230 VAC ± 15% 50 Hz 230 VAC ± 15% 50 Hz 230 VAC ± 15% 50 Hz
Battery 6 V rechargeable 6 V rechargeable 6 V rechargeable
SMPS 90 V to 270 V 90 V to 270 V 90 V to 270 V
Operating Temperature -20°C to + 55°C -20°C to + 55°C -20°C to + 55°C
PHYSICAL
Size 80 x 200 cm approx 80 x 200 cm approx 80 x 200 cm approx
Weight Approx 50 Kg Approx 50 Kg Approx 25 Kg

MATERIAL TEST AND CERTIFICATION : As per NIJ standards. Tested by TBRL (DRDO) India and H.P. White Laboratory U.S.A
