| ASSEMBLING |
3 plates (Left, Right & Centre) -Can be conveniently assembled & dismantled.
|
| HANDLING |
Two convenient carrying handles provided.
|
| DIMENSIONS |
|
PER PLATE |
PER PLATE |
| Height |
1200 mm |
1900 mm |
| Width |
700 mm |
750 mm |
| Total Morcha Weight |
<160 kgs |
<250 kgs |
|
| FIRING PORT |
- No compromise on BP properties of steel due to fi tments.
- Joints are tested for maintenance BP property.
- No gap between sheets in assembled morcha.
|
| WEIGHT OF MORCHAS |
Less than 160 Kgs.
|
| COLOUR |
Green / Disruptive / Camoufl age pattern / as per user requirement. |
| LOCKING ARRANGEMENTS |
Convenient locking arrangements for assembling & dismantling. |
| PROTECTION LEVEL |
| At 90 degree angle for each panel |
1200 mm Morcha |
1900 mm Morcha |
| 6 shots from SLR (7.62mm X 51mm) at Distance of 10 mtrs |
Yes |
Yes |
| 6 shots from AK-47 (7.62mm x 39mm) at a distance of 10 mtrs. |
Yes |
Yes |
| 6 shots from INSAS Rifl e at a distance of 10 mtrs. |
No |
Yes |
| *(Note: Minimum distance between shots less than 20mm. The distance of shots from the edges would not be less than 30mm.) |
|
| REPLACEMENTS |
Modular structure for easy replacement. |
| PROVISION OF WHEELS |
Detachable wheels can be provided. |
